| Title: | Guide to the 3 D pattern fitting in coordinate metrology |
| Authors: | Hutzschenreuter, Daniel, Physikalisch-Technische Bundesanstalt (PTB), Fachbereich 1.1 Masse - Weitergabe der Einheit, Braunschweig, ORCID: 0000-0002-9095-0063 |
| Contributors: | HostingInstitution: Physikalisch-Technische Bundesanstalt (PTB), ISNI: 0000 0001 2186 1887 ProjectLeader: Härtig, Frank, Physikalisch-Technische Bundesanstalt (PTB), Abteilung 1, Mechanik und Akustik, Braunschweig ProjectLeader: Schmidt, Markus, Werth Messtechnik GmbH, Gießen, Germany |
| Pages: | 45 |
| Language: | en |
| DOI: | 10.7795/530.20170606EN |
| Version: | 1 |
| Resource Type: | Text / Guide |
| Publisher: | Physikalisch-Technische Bundesanstalt (PTB) |
| Rights: |
https://creativecommons.org/licenses/by/3.0/de/legalcode CC-BY |
| Relationships: | IsVariantFormOf: DOI 10.7795/530.20170606DE Documents: DOI 10.7795/710.20170606 |
| Dates: |
Available: 2017-06-28 Created: 2017-05-23 |
| File: |
Download File
(application/pdf)
2.77 MB (2901028 Bytes)
MD5 Checksum: 67fbe009d692dde886eafaad8f1b8435 SHA256 Checksum: d003957cfa8ccfdcad7ac48563e922cd8b41b77d88a66edafc598339b7f5ab5d |
| Keywords: | coordinate metrology ; hole pattern fitting ; example applications ; application guide ; modelling |
| Abstract: | The guide provides a comprehensive overview to the application of 3D hole pattern fitting in coordinate metrology. Its focus is the development of mathematical models for a simulation of product assembly. Inspection tasks of workpieces with Maximum material condition according to the international standard ISO 2692 are subject to these models. Among general recommendations, the guide provides detailed informations for three example application. These are the fitting of flange rings with associated datum systems, the fit of mixed patterns with cylinder elements and pairs of planes as well as the general 3D fit of non parallel cylinder patterns. |
| Citation: | HUTZSCHENREUTER, Daniel. Guide to the 3 D pattern fitting in coordinate metrology. Physikalisch-Technische Bundesanstalt (PTB), 2017. DOI: 10.7795/530.20170606EN |
