Title: Evaluation of composite voltage test parameters
Authors: Schlüterbusch, Tim Christoph, Physikalisch-Technische Bundesanstalt, Fachbereich 2.3, Elektrische Energiemesstechnik
Meisner, Johann, Physikalisch-Technische Bundesanstalt, Fachbereich 2.3, Elektrische Energiemesstechnik
Gerdinand, Frank, Physikalisch-Technische Bundesanstalt, Fachbereich 2.3, Elektrische Energiemesstechnik
Passon, Stephan, Physikalisch-Technische Bundesanstalt, Fachbereich 2.3, Elektrische Energiemesstechnik
Contributors: HostingInstitution: Physikalisch-Technische Bundesanstalt, ISNI: 0000 0001 2186 1887
Resource Type: Text / Conference Article
Publisher: Physikalisch-Technische Bundesanstalt
Rights: Download for personal/private use only, if your national copyright law allows this kind of use.
Dates: Available: 2023-03-03
Created: 2022
File: Download File (application/pdf) 556.56 kB (569915 Bytes)
MD5 Checksum: d2ee80667689130c41638a71a58e702f
SHA256 Checksum: 18b23618817095cc609e881ea135e4c01dbb0cb9e046e09ea09e8af81fe2512a
Keywords: composite ; impulse ; high voltage ; test ; calibration
Abstract: The integration of renewable energy sources into the power grid and the extension of power transfer capabilities is one important step towards a reduction in CO2 emissions, a sustainable infrastructure and environment friendly power generation. In the electric grid this is causing a shift from the centralized generation of energy by big rotating AC generators towards more complicated, distributed, often semiconductor-based grid components using DC power in the process of power generation and often higher system voltages. The latter is underlined by the trend of ultra high voltage (UHV) power transmission. This leads to the need of more adequate, adapted test principles for the examination of the capabilities of grid components. In this context the work on the next revision of the standard IEC 60060 series considers the implementation of combined and composite voltages for impulse voltage tests. Until now there is no uniform procedure for the evaluation of the parameters of these novel test voltages. In particular for the case of more complex composite wave shapes. The Example this paper features is an impulse superimposed to a 50 Hz AC signal which record does cover only a small number of whole periods. In this paper we would like to investigate approaches in how to obtain concise and comparable results when working with combined and composite test voltages. These voltages consist out of lightning impulses (LI) or switching impulses (SI) superimposed to a conventional power supply voltage that is either an AC or a DC Voltage. Subject to this investigation is also the use of nonlinear regression in the process of the evaluation.
Citation: T.C. Schlüterbusch, J. Meisner et al., "Evaluation of composite voltage test parameters", AMPS 2022 - IEEE International Workshop on Applied Measurements for Power Systems, Cagliari, 2022, pp. 1-5. DOI: 10.1109/AMPS55790.2022.9978875
Funding: European Commission (EC), ISNI: 0000 0001 2162 673X, Grant Title: Support for standardisation of high voltage testing with composite and combined wave shapes, Grant Number: EMPIR 19NRM07 HV-com²
