| Title: | Application of Coordinate Measuring Machines (CMMs) : Guideline DKD-R 4-5 |
| Authors: |
Grimm, Volker, QS Grimm GmbH, Gutach Hageney, Jan, eumetron GmbH, Aalen Heißelmann, Daniel, Physikalisch-Technische Bundesanstalt (PTB), Fachbereich 5.3, Koordinatenmesstechnik Herweg, Jonathan, DIMETEC Elektro GmbH, Gevelsberg Kirchner, Bernd, WENZEL Metrology GmbH, Wiesthal Show all authors (12) |
| Contributors: | HostingInstitution: Physikalisch-Technische Bundesanstalt (PTB), ISNI: 0000 0001 2186 1887 |
| Pages: | 19 |
| Language: | en |
| DOI: | 10.7795/550.20240123 |
| Version: | 12/2023 |
| Resource Type: | Text / Technical Requirement |
| Publisher: | Physikalisch-Technische Bundesanstalt (PTB) |
| Rights: |
https://creativecommons.org/licenses/by-nc-nd/3.0/de/ CC by-nc-nd 3.0 |
| Relationships: | IsVariantFormOf: DOI 10.7795/550.20231213 |
| Dates: |
Available: 2024-01-24 Created: 2023-12 |
| File: |
Download File
(application/pdf)
505.01 kB (517133 Bytes)
MD5 Checksum: 40c367f7fc6cdcda24ca383e09ae57d1 SHA256 Checksum: bb5d411ab319a8e1f4555743a5773b61a9750fa4ed271588ba82647896b9b49a |
| Keywords | Coordinate Measuring Machines ; CMM ; DIN EN ISO/IEC 17025 |
| Abstract: | This guideline serves to implement the requirements of DIN EN ISO/IEC 17025 for the use of coordinate measuring machines (CMMs). Criteria are specified both for stationary measuring technology in so-called measuring rooms (cf. VDI/VDE 2627 Part 1) as well as for portable systems used at the customer’s premises(indoors) or outdoors. The described good laboratory practice describes aims to ensure the determination of valid results. The guideline is aimed at accredited calibration and testing laboratories as well as industrial users in need of QA measures due to the requirements of other standards and guidelines (e.g. DIN EN ISO 9001, IATF 16949). This guideline describes the current status of technology. The requirements are largely based on requirements defined in the relevant standards and guidelines, in particular the series of standards VDI/VDE 2617, VDI/VDE 2630, VDI/VDE 2634 and DIN EN ISO 10360 for measurement and testing of coordinate measuring machines (CMMs) as well as the series of standards DIN EN ISO 14253, DIN ISO/TS 15530, ISO/TS 23165, ISO/TS 17865 and relevant standards on form and positional tolerances used among other things for defining a competent measurement strategy. Moreover, the requirements for climatic conditions in the measuring rooms (criteria, verification, and monitoring) are described in the VDI/VDE 2627 series of guidelines. |
| Citation: | Guideline DKD-R 4-5 Application of Coordinate Measuring Machines (CMMs), Edition 12/2023, Revision 0, Physikalisch-Technische Bundesanstalt, Braunschweig and Berlin. DOI: 10.7795/550.20240123 |
