Good Practice Guide on Making Rectangular Waveguide Connections at Frequencies above 100 GHz
Authors:
Authors:
Kuhlmann, Karsten, Physikalisch-Technische Bundesanstalt (PTB), Fachbereich 2.2, Hochfrequenz und Felder, ORCID: 0000-0002-4022-7061
Probst, Thorsten, Physikalisch-Technische Bundesanstalt (PTB), Fachbereich 2.2, Hochfrequenz und Felder, ORCID: 0000-0002-6778-5215
Ridler, Nick, National Physical Laboratory, Teddington, UK, ORCID: 0000-0002-1462-2914
Watts, James, Flann Microwave Ltd, Bodmin, UK, ORCID: 0000-0003-2639-3191
Contributors:
Contributors:
HostingInstitution: Physikalisch-Technische Bundesanstalt (PTB), ISNI: 0000 0001 2186 1887
Pages:
Pages:
25
Languages:
Languages:
en
DOI:
DOI:
10.7795/530.20190805
Resource Type:
Resource Type:
Text / Guide
Publisher:
Publisher:
Physikalisch-Technische Bundesanstalt (PTB)
Rights:
Rights:
https://creativecommons.org/licenses/by-nd/4.0/deed.en
CC BY-ND 4.0
Relationships:
Relationships:
References: DOI 10.7795/720.20200625
Dates:
Dates:
Available: 2019-08-09
Created: 2019-07
Classifications:
Classifications:
INSPEC B1310 Waveguides and microwave transmission lines ; INSPEC B1320 Waveguide and microwave transmission line components ; INSPEC B2180E Connectors ; INSPEC B5210C Radiowave propagation ; INSPEC B7130 Measurement standards and calibration
File:
File:
Download File (application/pdf) 1.40 MB (1467196 Bytes)
MD5 Checksum: e1541deb08e233bcb00d974e53117636
SHA256 Checksum: 4eb1437249f131a013ec299e87cbeb66969fd508294f5df8d2586f611048fae8
Abstract:
Abstract:
At frequencies of approximately 100 GHz and above, rectangular metallic waveguide is often the preferred transmission medium for making reliable, precision, measurements. A prerequisite for these types of measurements is the use of the correct types of waveguide interface, and, the need to follow the correct operating procedures. This document is aimed at people interested in making reproducible measurements with relatively low measurement uncertainty, in rectangular waveguide, at these frequencies. It can be considered as a supporting document for existing standards that are available for waveguide and waveguide interfaces used at these frequencies (e.g. as published by IEEE, IEC, MIL, EIA, etc). This document concentrates on rectangular waveguides. However, many aspects that are presented might also be applicable to circular waveguides.
